HydroFlame™ Drop-In & Under Deck Firestop Devices, Accessories Safety Caps for Drop-In Firestop Devices
Post-Pour Firestop Systems
HoldRite HydroFlame Drop-In & Under Deck Accessories are the essential finishing components for a complete, code-compliant firestop system. Built to support a wide range of penetrant types and deck configurations, these accessories ensure safe, efficient, and professional installations.
From UL-listed steel sleeves that seal horizontal cores in precast and hollow core decks to OSHA-compliant safety caps that protect open holes, each accessory is engineered for performance and reliability.
- UL-listed steel sleeves for horizontal penetrations in precast and hollow core decks
- Safety caps sized for standard fire-rated wall widths and OSHA hole cover compliance
- Compatible with floor drains, shower drains, and closet flanges
- FBC-compatible for CPVC piping systems
- Mold and mildew resistant (ASTM G21 tested)
- Designed to integrate seamlessly with HydroFlame Drop-In and Under Deck Devices
Item # |
Material |
A |
B |
C |
Cad |
|---|---|---|---|---|---|
| DID-SC-2000 | Material N/A 14 GA | A N/A 5.4 in | B N/A 4.50 in | C N/A 0.09" / 14 |
Cad
N/A
|
| DID-SC-3000 | Material N/A 13 GA | A N/A 6.9 in | B N/A 5.50 in | C N/A 0.11" / 13 |
Cad
N/A
|
| DID-SC-4000 | Material N/A 12 GA | A N/A 7.9 in | B N/A 6.40 in | C N/A 0.12" / 12 |
Cad
N/A
|
| DID-SC-6000 | Material N/A 12 GA | A N/A 9.9 in | B N/A 8.40 in | C N/A 0.12" / 12 |
Cad
N/A
|
