LARGE BORE SharkBite Commercial is an extensive range of SharkBite Fitting and full flow Ball Valves in
sizes 1¼”, 1½”, 2” Copper Tube Size (CTS) suitable for use with Copper, PEX,(SharkBite Tube Liner must be
fitted to the PEX Pipe) and CPVC pipe. Use in commercial and residential applications for potable water,
hydronic heating, chilled water and general water distribution for irrigation.
Unit of Measure
Type |
N/A Reducer |
Connection Type |
N/A SharkBite 2XL |
Size |
N/A 3/4 |
Weight |
N/A 0.482 lb |
L |
N/A 3.35 in |
H |
N/A 2.13 in |
L1 |
N/A 2.15 in |
Body |
N/A DZR Brass-Lead Free Alloy |
O Ring |
N/A Chloramine Resistant EDPM O-Ring |
Tube Liner |
N/A Copper |
Grab Ring |
N/A 316 Stainless Steel |
SharkBite Cartridge Assembly |
N/A Acetyl Copolymer |
Specification |
N/A SharkBite Commercial ttings are designed to operate over a wide range: Temperatures from 20°F to 200°F. Maximum working pressure of 200psi. |
Features and Benefits |
N/A
Quick Connect: No tools, soldering, clamps, unions or glue required. Cut pipe square, de-burr to remove rough edges/debris, mark the pipe for correct depth and push to get a pressure ready connection every time. Quick Disconnect: Disconnect in seconds by sliding the De-Mount Tool down the pipe to engage the demount lugs and rotate clockwise to lock the open position leaving both hands free, you can now remove the pipe. SAFE-Recessed Release Collar: Commercial SharkBite require a special Demount Tool and cannot be accidentally disconnected/released. Extensive Range Including Slip Feature on Couplings and Tee’s: When repairing or tapping into existing pipe with “Push-Fittings” you must be able to either move the tting or the pipe to ensure the pipe is engaged fully into the tting. With rigid pipe like copper the only way with “Push-Fittings” is to have a SLIP feature to allow easy installation when tapping into existing pipe. Easy Installation: Unlike the tool intensive connection methods there is NO need to send multiple tters to a job, SharkBite Commercial has been designed to be installed or removed by one person. All ttings are lubricated for easy connection and by tting the De-Mount Tool before engaging the pipe the force required can be reduced further. With the De-Mount Tool locked on you also have hands free disconnection. WET OR DRY: No waiting for copper tube to dry before soldering or glue to cure, SharkBite makes an instant connection in seconds. No Tools: Unlike alterative tool intensive connections systems, SharkBite has no special tooling required for installation. No Time: Fastest connection - CUT-PUSH-DONE. Easy access to small or con ned places. No Flame - Does not require re permit or re marshal. No Waste: Should you make an error or simply want to change your installation, no problem for SharkBite. Simply remove and re-use. (Fittings used for repeated testing must not be used in any permanent application). Fittings Cannot be Disassembled: SharkBite Commercial Fitting are factory assembled and components cannot be removed. Long Pipe Engagement: Provides pipe support against lateral pipe forces. Lead Free (LF) Dezinci cation Resistance (DZR) Brass: Exceeds current no lead legislation - AB1953 or NSF372. Suitable for underground installation subject to local code authorites/inspectors. Dezinci cation properties (DZR) exceed ISO6509 and NSF-14. Environmentally Friendly: Remove and re-use ttings, no need to be scrapped. No heat is required for installation. |
Certifications |
N/A IAPMO IGC 157: Ball Valves- This standard covers material, testing, dimensional and performance requirements. ASSE1061: Fittings-Performance requirements for removable & non-removable push- t ttings. NSF/ ANSI 61, NSF/ANSI 372, ASSE 1061 |
